Description
Schneider C10B3TM032 | Circuit breaker ComPacT NSX100B, 25kA at 415VAC, TMD trip unit 32A, 3 poles 3d
Technical Specifications C10B3TM032
-
Product Reference: C10B3TM032
-
Product Series: ComPacT NSX100B
-
Type: Molded Case Circuit Breaker (MCCB)
-
Rated Operational Voltage: Up to 415 VAC
-
Interrupting Capacity: 25 kA at 415 VAC
-
Number of Poles: 3 poles (3P)
-
Rated Current: 32 Amperes
-
Trip Unit Type: TMD (Thermal Magnetic)
-
Mounting Mode: Fixed
-
Breaking Capacity Category: B (Basic breaking capacity for standard protection)
-
Conformity Standards: IEC 60947-2
-
Frequency: 50/60 Hz
-
Control Type: Manual operation
Key Features
-
Compact Size: The NSX100B frame allows for space-saving installation in panels while maintaining high performance.
-
Reliable Protection: Offers both thermal (overload) and magnetic (short-circuit) protection through its integrated TMD trip unit.
-
High Breaking Capacity: Can interrupt fault currents up to 25 kA, making it suitable for demanding industrial applications.
-
Ease of Installation: Simple to mount with screw-type terminals and compatible with various accessories like auxiliary contacts and shunt trips.
-
Durability: Robust construction ensures a long operational life even in tough environments.
-
Clear Status Indication: Trip status and handle position give immediate visual feedback on circuit conditions.
Applications
-
Industrial Distribution Panels: Used to protect machinery and downstream equipment from overload and short-circuit conditions.
-
Commercial Electrical Boards: Ideal for main or sub-feeders in commercial buildings such as offices, shopping centers, and hotels.
-
Control Panels: Provides reliable protection for control circuits in automated systems.
-
Renewable Energy Systems: Suitable for photovoltaic (solar) or wind energy installations that require reliable circuit protection.
-
Backup Generator Systems: Protects generator outputs and ensures safe operation under fault conditions.
