Description
Schneider C10B3TM050 | Circuit breaker ComPacT NSX100B, 25kA at 415VAC, TMD trip unit 50A, 3 poles 3d
Technical Specifications C10B3TM050
-
Product Reference: C10B3TM050
-
Series: ComPacT NSX100B
-
Device Type: Molded Case Circuit Breaker (MCCB)
-
Rated Current (In): 50 Amperes
-
Rated Voltage: Up to 415 VAC
-
Breaking Capacity: 25 kA at 415 VAC
-
Trip Unit Type: TMD (Thermal Magnetic)
-
Poles: 3 poles (3P)
-
Mounting Type: Fixed
-
Frequency: 50/60 Hz
-
Standards: Complies with IEC 60947-2
-
Operation: Manual control with toggle handle
Key Features
-
Thermal-Magnetic Trip Unit: Combines thermal protection against overloads and magnetic protection against short-circuits for precise and reliable operation.
-
Compact and Modular: Saves space in panels and allows easy integration with other ComPacT components.
-
High Interrupting Capacity: Capable of handling fault currents up to 25 kA without damage, ensuring system stability and user safety.
-
Clear Status Indication: Provides visible status of ON, OFF, or TRIPPED positions for quick diagnostics.
-
Accessory Compatibility: Supports a wide range of optional accessories including auxiliary contacts, motorized operation, and remote tripping modules.
-
Robust and Durable: Built to withstand tough conditions and high operational demands over extended periods.
Applications
-
Industrial Electrical Distribution: Ideal for protecting production equipment, control panels, and machinery from electrical faults.
-
Commercial Buildings: Used in power distribution boards for offices, shopping malls, hotels, and hospitals.
-
Infrastructure and Utilities: Reliable choice for electrical protection in public facilities and utility systems.
-
Renewable Energy Installations: Suitable for use in solar PV and wind energy systems requiring dependable circuit protection.
-
Data Centers and IT Installations: Helps protect critical power supply lines to servers and networking equipment.
