Description
Schneider C11N6TM032L | Circuit breaker, ComPacT NSXm 63N, 50kA/415VAC, 4 poles 3D (neutral not protected), TMD trip unit 32A, EverLink lugs
Technical Specifications C11N6TM032L
-
Product Reference: C11N6TM032L
-
Series: ComPacT NSXm 63N
-
Device Type: Molded Case Circuit Breaker (MCCB)
-
Rated Current (In): 32 Amperes
-
Rated Operational Voltage: Up to 415 VAC
-
Breaking Capacity: 50 kA at 415 VAC
-
Number of Poles: 4 poles (3D – 3 protected phases + switched, non-protected neutral)
-
Trip Unit Type: TMD (Thermal Magnetic)
-
Neutral Protection: Neutral not protected, but switched
-
Connection Type: EverLink lugs
-
Mounting Mode: Fixed
-
Standards Compliance: IEC 60947-2
-
Operating Frequency: 50/60 Hz
-
Control Type: Manual toggle operation
Key Features
-
High Fault Interruption Capability: With a 50 kA breaking capacity, this breaker provides strong protection in demanding fault conditions.
-
Thermal-Magnetic Trip Unit: Built-in protection against overloads and short-circuits ensures safe system operation.
-
EverLink Lug Technology: Patented EverLink connections maintain tight, stable cable connections, reducing risk of overheating and loosening due to vibration.
-
4-Pole 3D Switching: Three protected phases and one switched (but unprotected) neutral for enhanced system safety.
-
Compact Design: Small frame size fits easily into space-constrained panels while offering robust performance.
-
Status Indication: ON, OFF, and TRIPPED positions are clearly indicated for fast, easy diagnostics.
-
Accessory Ready: Compatible with a wide range of optional accessories including auxiliary contacts, shunt trips, and under-voltage releases.
Applications
-
Industrial Panels: Used in protection of machinery, control circuits, and automated systems.
-
Commercial Power Distribution: Suitable for sub-panels in shopping centers, hotels, office buildings, and retail outlets.
-
Critical Infrastructure: Ideal for applications in hospitals, data centers, transport facilities, and utilities.
-
Renewable Energy Systems: Applicable in solar PV installations and wind energy systems where reliable and high-capacity protection is needed.
-
Backup and Emergency Systems: Provides protection and isolation for generators and backup power circuits.
