Schneider C11N6TM040L | circuit breaker ComPacT NSXm N (50 kA at 415 VAC), 4P 3d, 40 A rating TMD trip unit, EverLink connectors

Description

Schneider C11N6TM040L | circuit breaker ComPacT NSXm N (50 kA at 415 VAC), 4P 3d, 40 A rating TMD trip unit, EverLink connectors

Technical Specifications C11N6TM040L

• Product Reference: C11N6TM040L

• Product Range: ComPacT NSXm N

• Device Type: Molded Case Circuit Breaker (MCCB)

• Rated Current (In): 40 Amperes

• Rated Operational Voltage: Up to 415 VAC

• Breaking Capacity: 50 kA at 415 VAC

• Number of Poles: 4 poles (3D – 3 protected poles + 1 switched neutral, not protected)

• Trip Unit Type: TMD (Thermal Magnetic)

• Neutral Protection: Neutral is switched but not protected

• Connection Technology: EverLink lug connectors

• Mounting Type: Fixed installation

• Standards Compliance: IEC 60947-2

• Frequency: 50/60 Hz

• Control Method: Manual toggle

Key Features

• High Short-Circuit Protection: Capable of interrupting fault currents up to 50 kA at 415 VAC, ideal for critical applications.

• Thermal-Magnetic Trip Unit: Provides dual protection for overload (thermal) and short-circuit (magnetic) events.

• EverLink Lug Connectors: Maintain secure, vibration-resistant connections, reducing the risk of overheating due to loose wiring.

• Compact Design: Small footprint suitable for confined distribution boards and space-limited applications.

• 4-Pole (3D) Configuration: Ensures three-phase protection with a switched neutral, increasing system isolation and safety.

• Modular System Compatibility: Accepts a wide range of auxiliary and control accessories, such as shunt trips and auxiliary contacts.

• Clear Status Display: Visual indication of ON/OFF/TRIP status for quick operational awareness and troubleshooting.

Applications

• Industrial Control Panels: Protects sensitive equipment in manufacturing, processing plants, and automation systems.

• Commercial Distribution Boards: Used in office buildings, shopping centers, hotels, and healthcare facilities.

• Data Centers and Telecommunications: Offers reliable circuit protection for critical IT infrastructure.

• Renewable Energy Installations: Suitable for solar PV and wind systems requiring compact, high-capacity protection.

• Public Infrastructure Projects: Used in electrical panels in transportation systems, water facilities, and government buildings.

• Backup Power Systems: Safeguards connections to generators, inverters, and UPS systems.
