Description
Schneider C12E3TM160L | Circuit breaker ComPacT NSXm E (16kA at 415VAC), 3 Poles 3d, 160A rating TMD trip unit, EverLink connectors
Specifications C12E3TM160L
-
Product Name: Schneider ComPacT NSXm E Circuit Breaker
-
Reference Code: C12E3TM160L
-
Type: MCCB – Molded Case Circuit Breaker
-
Breaking Capacity: 16 kA at 415 VAC (IEC 60947-2)
-
Poles: 3-pole, 3d (3 protected poles)
-
Rated Current (In): 160 A
-
Trip Unit Type: TMD (Thermal Magnetic Trip Unit)
-
Terminal Type: EverLink connectors
-
Mounting: Panel-mounted or within distribution boards
-
Frequency: 50/60 Hz
-
Voltage Rating: Up to 415 VAC
-
Range: ComPacT NSXm E
-
Certifications: IEC compliance, CE marking
Features
-
Compact design for optimized space utilization in panels
-
TMD trip unit provides dual protection:
-
Thermal for overload
-
Magnetic for short circuits
-
-
EverLink terminal technology ensures a consistent and secure clamping force over time, minimizing connection failures due to loosening
-
Easy installation with fixed mounting and top/bottom wiring flexibility
-
Long electrical and mechanical endurance, suitable for heavy-duty applications
-
Supports integration with auxiliary accessories such as auxiliary contacts, shunt trip, and undervoltage release
-
Clearly visible ON/OFF indication and manual operation handle
Applications
-
Ideal for use in low-voltage power distribution systems across commercial, industrial, and residential facilities
-
Provides circuit protection for equipment like HVAC units, lighting, motors, and socket outlets
-
Suitable for main or sub-main circuit protection in electrical panels
-
Widely used in factories, data centers, hospitals, and commercial buildings
-
Applicable in renewable energy setups and smart electrical panels requiring safe, compact breakers with reliable connections
