Description
Schnieder A9N61539 | miniature circuit breaker – C60H – 2 poles – 63 A – C curve
Technical Specifications
-
Model Number: A9N61539
-
Product Series: C60H
-
Device Type: Miniature Circuit Breaker (MCB)
-
Number of Poles: 2 (Double Pole)
-
Rated Current: 63 Amps
-
Tripping Curve: C Curve
-
Operating Voltage: 230/400V AC
-
Frequency: 50/60 Hz
-
Breaking Capacity: Up to 6 kA
-
Mounting: DIN Rail
-
Degree of Protection: IP20 (when used in an appropriate enclosure)
-
Standards: IEC 60898-1 compliant
Key Features and Benefits
-
Provides reliable protection against overload and short-circuit conditions
-
C curve tripping allows tolerance for temporary current surges typically caused by motor startups
-
Double-pole mechanism ensures complete disconnection for enhanced safety
-
Thermal-magnetic trip unit offers dual protection
-
Clear visual indicator for ON/OFF/TRIPPED status
-
Compact design suitable for space-constrained distribution boards
-
Manual reset function simplifies maintenance and troubleshooting
-
Built to last, with high mechanical and electrical endurance
Applications
Residential:
-
Protection of high-demand circuits such as water heaters, air conditioners, and electric ovens
-
Ideal for use in main or sub-distribution boards
Commercial:
-
Power protection for HVAC systems, lighting panels, and high-power appliances in offices, shops, or restaurants
-
Ensures stable operation of electrical distribution in buildings
Industrial:
-
Suitable for protecting motors, pumps, and other inductive loads in manufacturing environments
-
Used in control panels, machinery feeds, and production lines
Backup Power Systems:
-
Effective in generator output circuits or uninterruptible power supply (UPS) systems
-
Offers secure switching and protection in high-load emergency systems
