Description
Schneider A9N61515 | miniature circuit breaker – C60H – 1 pole – 32 A – C curve
Technical Specifications A9N61515
-
Manufacturer: Schneider Electric
-
Product Code: A9N61515
-
Series: Acti9 C60H
-
Device Type: Miniature Circuit Breaker (MCB)
-
Number of Poles: 1 Pole
-
Rated Current (In): 32 A
-
Tripping Curve: Type C (trips at 5 to 10 times the rated current)
-
Rated Operational Voltage: 230/400 V AC
-
Rated Frequency: 50/60 Hz
-
Breaking Capacity:
-
6 kA according to IEC/EN 60898-1
-
-
Mounting Method: DIN rail mounting (standard 35 mm rail)
-
Terminal Type: Screw terminal (top and bottom)
-
Degree of Protection: IP20 (when installed in enclosure)
-
Operating Temperature: -25°C to +60°C
-
Mechanical Endurance: > 20,000 operations
-
Electrical Endurance: > 10,000 operations
-
Standards:
-
IEC/EN 60898-1
-
IEC/EN 60947-2
-
Main Features:
-
32 A Current Rating
Offers robust protection for mid-capacity loads, including high-demand sockets and motor circuits. -
C Curve Tripping
Optimized for applications with moderate inrush current, ensuring sensitive yet non-nuisance tripping. -
Compact Modular Design
Saves space in distribution panels while maintaining full functionality and safety. -
Reliable Breaking Performance
Handles short circuits up to 6,000 A without compromising device integrity or surrounding circuits. -
Easy Installation
Quick-fit DIN rail mounting and secure terminal connections simplify setup and maintenance. -
Extended Lifespan
High endurance in both mechanical and electrical operations for long-term reliability.
Applications:
Residential:
-
Lighting circuits, kitchen appliances, air conditioning units.
-
Use in apartment buildings and private homes.
Commercial:
-
Office and retail power circuits.
-
Server rooms, IT racks, and energy control panels.
Light Industrial:
-
Automation systems, machine control panels.
-
Protection of single-phase motors and tools.
Public Infrastructure:
-
Schools, healthcare facilities, public buildings.
-
Emergency systems, lighting, and auxiliary loads.
