Description
Schneider LV510335 | circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 3P 3d
Technical Specifications
- Model Number: LV510335
- Series: EasyPact CVS
- Breaker Type: Molded Case Circuit Breaker (MCCB)
- Rated Current: 63A
- Frame Size: CVS100F
- Number of Poles: 3P (Three-Pole)
- Breaking Capacity: 36 kA at 415V AC
- Trip Unit Type: Thermal-Magnetic (TM-D)
- Protection Functions: Overload (thermal) and short-circuit (magnetic) protection
- Voltage Rating: Suitable for 415V AC systems
- Mounting Type: Fixed mounting
- Compliance: Conforms to IEC 60947-2
Key Features
-
Reliable Overcurrent Protection:
- Thermal protection offers overload defense, while magnetic protection provides fast reaction to short circuits, ensuring equipment safety.
-
High Breaking Capacity (36 kA at 415V AC):
- Capable of handling fault currents up to 36 kA, this breaker provides reliable protection in high-demand applications.
-
Robust and Compact Design:
- Built for high durability and designed to save space, it’s ideal for industrial and commercial environments.
-
Three-Pole (3P) Configuration:
- Ideal for three-phase electrical systems, providing balanced and efficient circuit protection.
-
Thermal-Magnetic TM-D Trip Unit:
- Features precise thermal and magnetic protection to handle different fault conditions, ensuring protection against overloads and short circuits.
-
Compliant with International Standards:
- Meets the strict requirements of IEC 60947-2, ensuring safety, performance, and compliance with global standards.
Applications
- Industrial Applications: Ideal for use in factories, manufacturing plants, and heavy machinery.
- Commercial Buildings: Suitable for offices, shopping malls, and business centers requiring reliable circuit protection.
- Power Distribution Systems: Perfect for electrical panels and distribution boards to ensure safe power management.
- Renewable Energy Installations: Can be used in solar power systems and other renewable energy applications.
- Infrastructure Projects: Essential for public utilities and large-scale installations requiring high capacity protection.
